POWERFUL, COMPACT BASS PERFORMANCE
The Alpine S2‑W10D4 is a high‑output 10″ subwoofer engineered to deliver deep, dynamic low‑end response in a compact design. Part of Alpine’s S‑Series lineup, this subwoofer adds impactful bass that enhances the fullness and excitement of your music without taking up excessive space.
DEEP, CONTROLLED LOW‑END RESPONSE
Featuring a rigid 10″ woofer with an optimized surround and high‑excursion design, the S2‑W10D4 produces tight, well‑defined bass that adds depth and presence to every track. Its tuned suspension ensures low frequencies remain articulate and controlled, even at higher output levels.
HIGH‑POWER HANDLING
Built for reliable performance under demanding conditions, the S2‑W10D4’s dual 4‑ohm voice coils provide flexible wiring options to match your amplifier’s capabilities. This flexibility helps you achieve efficient power delivery and strong output in a variety of setups.
CLEAR, DETAILED PERFORMANCE
Advanced suspension and a vented pole piece work together to reduce distortion and heat buildup, keeping bass tight and precise during extended listening sessions. This results in clean, impactful low‑frequency reproduction that complements the rest of your audio system.
STRAIGHTFORWARD INSTALLATION
Designed with standard mounting dimensions, the S2‑W10D4 fits a wide range of subwoofer enclosures and vehicle applications. Whether in sealed, ported, or custom boxes, this subwoofer delivers substantial low‑end impact with a straightforward setup.
VERSATILE SYSTEM ENHANCEMENT
Ideal for both factory and aftermarket audio systems, the S2‑W10D4 significantly enhances bass performance, punch, and overall sound quality. Its combination of power, precision, and efficiency makes it an excellent choice for everyday listening or high‑output systems.
|
|
Size
|
10-inch
|
|
Voice Coil
|
DVC
|
|
Impedance
|
4 Ohms
|
|
RMS Power Rating (Watts)
|
600 |
|
Peak Power Rating (Watts)
|
1800 |
| Cone Material |
Carbon Fiber/Polypropylene
|
Surround Material
|
HAMR Rubber Surround
|
Free Air
|
No
|
Sensitivity
|
84.9dB at 1 Watt
|
Frequency Response
|
25-215hz
|
|
Top Mount Depth (Inches)
|
4 11/16"
|
Bottom Mount Depth (Inches)
|
|
Cutout Diameter (Inches)
|
8 15/16"
|
Vas (liters)
|
24.9 |
Fs (Hz)
|
32Hz
|
Xmax (millimeters)
|
15
|
Warranty
|
1 Year
|
