Overview

Sleek, Compact, Powerful

The PA D5000.5 is capable of bridging two full-range channels into a single full-range channel with higher output power. For instance, the front channels (FL and FR) when wired correctly will increase the output power from 70W per channel to 200W per channel (for a 4 ohm load). The same can be done for the rear channels (RL and RR). The most common configurations are four full-range channels and a subwoofer channel, or two bridged full-range channels and a subwoofer channel.

PA D5000.5 Features:

Super-efficient class D design—runs much cooler than conventional amps.

High-speed MOSFET switching—power supply with outputs stable into 2 ohm loads for full range channel speakers and 1 ohm loads for subwoofer channel.

Protection—thermal, DC offset, reverse DC voltage and short circuit protection.

Sub 1/Sub 2 Inputs—line level inputs for subwoofer signal from head unit

SUB/INT source switch—in the INT position, the amplifier will filter the bass frequencies from the full range signal and send them to the subwoofer amplifier channel.

SUB sonic filter—attenuates the frequencies below the settings on the control.

Remote bass level control—set gain to match output from head unit.

Rear Full, HPF switch—selects between no filtering or a high pass filter to dial in your speakers' blending.

Channel mode switch (4CH/ST)—in the ST position, the amplifier sends the same signal to the front and rear channels.

Nickel-plated wire terminals & RCA connectors—ensure maximum signal transfer.

Stainless steel hardware—Used throughout and will not corrode in humid environments.

Features & Specifications

Number of Channels	5
Class	D
Peak Power Rating (Watts)
RMS Power Rating (Watts x Channels) - 4 Ohms	70 x 4 200 x 1
RMS Power Rating (Watts x Channels) - 2 Ohms	100 x 4 400 x 2
RMS Power Rating (Watts x Channels) - 1 Ohm	500 x 1
RMS Power Rating - Bridged	200 x 2
Minimum Impedance Unbridged (Ohms)	1 (Sub) 2 (4Ch)
Minimum Impedance Bridged (Ohms)	4 (4Ch)
THD at Rated RMS Power	1%
Bulit-in Crossover - Low Pass	Yes
Built-in Crossover - High Pass	Yes
High Pass Crossover Frequency (Hz)	40-4000hz
Low Pass Crossover Frequency (Hz)	80-4000hz
Signal-to-Noise Ratio	105dB
Bass Boost	No
Bass Remote Included	No
Fuse Rating	80A
CEA-2006 Compliant	Yes
Maximum Power Wire Gauge Size	4 Gauge
Warranty	1 Year
