MB Quart RW1-164 Reference 6.5" Mobile Subwoofer – 600 Watts
The MB Quart RW1-164 Reference Series 6.5" Mobile Subwoofer is a compact, high-performance subwoofer designed to deliver powerful low-frequency response where installation space is limited. Featuring a dual 4-ohm voice coil design, this subwoofer provides installation flexibility for custom mobile audio systems while delivering up to 600 watts of peak power handling.
Built with a rugged aluminum die-cast basket, vented motor structure, and high-power handling components, the RW1-164 is engineered for durability, thermal control, and accurate bass reproduction. Its compact 6.5-inch design makes it suitable for vehicles where a larger subwoofer enclosure is not practical.
Features
- Reference Series 6.5" mobile subwoofer
- 600 watts maximum power handling
- 300 watts RMS power handling
- Dual 4-ohm voice coil configuration
- Heavy-duty powder-coated aluminum die-cast basket
- Vented aluminum voice coil former
- High-energy vented motor assembly
- Double-stitched foam surround
- Dual poly-cotton spider design
- Push-in speaker terminals for easy installation
- Designed for sealed or vented custom enclosures
- Compact design for space-limited installations
- 1-year warranty
Specifications
- Product Type: Mobile Subwoofer
- Series: Reference
- Model: RW1-164
- Speaker Size: 6.5"
- Voice Coil Configuration: Dual Voice Coil (DVC)
- Voice Coil Impedance: 4 Ohms + 4 Ohms
- Peak Power Handling: 600 Watts
- RMS Power Handling: 300 Watts
- Sensitivity: 83dB
- Frequency Response: Designed for subwoofer applications
- Outside Diameter: 7.16"
- Cutout Diameter: 5.94"
- Mounting Depth: 4.17"
- Weight: Approximately 10.85 lbs
Design Features
-
Dual voice coil design: Allows flexible wiring configurations for different amplifier setups.
-
Aluminum die-cast basket: Provides strength, rigidity, and improved heat dissipation.
-
Vented motor assembly: Helps exchange heat during high-power operation for improved reliability.
-
Double-stitched surround and dual spider system: Helps maintain linear cone movement and reduce distortion.
-
Compact enclosure requirements: Makes it suitable for custom installations in vehicles with limited space.
Recommended Applications
- Cars
- Trucks
- SUVs
- Custom mobile audio builds
- Compact subwoofer enclosures
- OEM audio upgrades requiring additional bass
- High-performance systems with limited installation space
Installation Applications
- Add deep bass response to a factory audio system
- Build a compact subwoofer enclosure
- Pair with a dedicated mono amplifier
- Integrate into custom door, console, trunk, or under-seat installations
- Combine with MB Quart Reference Series amplifiers and speakers for a complete mobile audio system
Enclosure Recommendations
The RW1-164 is designed for custom enclosure installations. MB Quart recommends using an appropriately designed sealed or vented enclosure depending on the desired balance between sound quality and output level.
