MB Quart PK1-169 Premium 6x9" 2-Way Coaxial Speakers with Grilles – 220 Watts
Upgrade your vehicle’s factory audio system with the MB Quart PK1-169 Premium 6x9" 2-Way Coaxial Speakers. Designed for premium mobile audio performance, these speakers combine advanced materials, wide-dispersion tweeter technology, and high-quality construction to deliver detailed highs, smooth vocals, and strong midbass response.
The PK1-169 features a 1-inch Magnesium WideSphere™ tweeter with a tunable waveguide housing and removable phase lens. This design improves high-frequency dispersion and helps create a wider, more immersive soundstage for listeners throughout the vehicle.
A 6x9-inch aerated paper cone with mica blend provides a lightweight and rigid platform for accurate midrange and bass reproduction. The speaker also includes a reinforced composite frame, butyl rubber surround, high-temperature voice coil assembly, ventilation cooling, and corrosion-resistant connectors for dependable automotive performance.
Features
- Premium Series 6x9" 2-way coaxial speakers
- 220 watts peak power handling per pair
- 110 watts peak power handling per speaker
- 55 watts RMS power handling per speaker
- 1" Magnesium WideSphere™ dome tweeters
- Tunable waveguide tweeter housing
- Removable tweeter phase lens
- Aerated paper cone with mica blend
- Curvilinear cone geometry for improved upper midrange response
- Butyl rubber speaker surrounds
- Built-in premium coaxial crossover
- High-temperature voice coil wire on Kapton former
- Ventilated cooling design
- Aerospace-grade PA66 composite frame with 30% glass fiber
- Stainless steel push-and-insert connectors
- Protective grilles included
- Sold as a pair
Specifications
- Product Type: Mobile Coaxial Speakers
- Series: Premium
- Speaker Size: 6x9"
- Configuration: 2-Way Coaxial
- Impedance: 4 Ohms
- RMS Power Handling:
- 55 Watts per Speaker
- 110 Watts Per Pair
- Peak Power Handling:
- 110 Watts per Speaker
- 220 Watts Per Pair
- Frequency Response: 20Hz–22kHz
- Sensitivity: 85.5dB
- Tweeter Size: 1"
- Tweeter Material: Magnesium Dome
- Woofer Cone Material: Paper Fiber with Mica Blend
- Surround Material: Butyl Rubber
- Mounting Depth: Approximately 2.95"
- Cutout Dimensions: Approximately 8.77" x 6.06"
- Color: Black
- Warranty: 1 Year
Design Features
-
WideSphere™ tweeter technology improves off-axis high-frequency response and creates a larger listening area.
-
Mica-blended paper cone construction balances strength, sensitivity, and natural sound reproduction.
-
Composite reinforced speaker frame minimizes unwanted resonance.
-
Thermally managed voice coil design supports reliable operation during extended playback.
-
Integrated crossover network provides smooth transition between woofer and tweeter frequencies.
In the Box
- Two 6x9" Premium coaxial speakers
- Two protective grilles
- Mounting hardware
- Speaker connection accessories
- Installation documentation
Compatible Applications
- Cars
- Trucks
- SUVs
- Vans
- Factory 6x9" speaker locations
- Aftermarket mobile audio systems
- Custom vehicle audio installations
Applications
- Replace factory 6x9" speakers with premium full-range drivers
- Improve clarity and detail in OEM audio systems
- Add stronger midbass performance without separate tweeter installation
- Pair with MB Quart amplifiers for increased output
- Build a balanced front or rear speaker upgrade system
