JL Audio XD200/2v2, XD Series Class D Full-Range Amplifier, 100W x 2

Model: JL-XD200/2v2
UPC: 699440986007

JL Audio XD200/2v2, XD Series Class D Full-Range Amplifier, 100W x 2

JL Audio XD200/2v2, XD Series Class D Full-Range Amplifier, 100W x 2
Sold Out
Price Match Guarantee
Price Match Guarantee
AVLeaderz Cares! We are dedicated to offering the best value to our customers, always. We will match the price, at the time of purchase, on a Price Match Guarantee product if you find the same item at a lower price at a qualifying online retailer or at a local retail competitor's store. Here's how:

  • If you find a qualifying lower price online, call 1-866-859-0896 and provide a customer service agent the web site with the lower price.
  • On qualifying products, AVLeaderz will verify the current price to complete the price match.
Exclusions may apply including, but not limited to, items sold by Marketplace vendors, competitors' service prices, special daily or hourly sales, and items for sale the Sunday before Thanksgiving Day through the Monday after Thanksgiving. More Details
$449.99
JL Audio

60-DAY FREE & EASY RETURNS
Your purchase is backed by our AVLeaderz advantage satisfaction guarantee. Get Free & Easy Returns for 60 days from the day you receive your order.
FREE SHIPPING & FREE RETURNS
Add to wishlist

To add this product to your wish list you must Login or Register

Not Available for Shiping Outside the United States

Questions? We're here to help.

866-859-0896 ChatEmail Us

PROP 65 WARNING

WARNING: This product can expose you to chemicals including arsenic, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov

This tiny amplifier packs a serious full-range punch, delivering a staggering 100 watts per channel into 2 ohms (14.4V, 1% THD). The breakthrough that makes this much power possible in such a small chassis is our NexD™ ultra-high-speed switching design, which allows for full bandwidth Class D operation with extremely low distortion and outstanding efficiency.

The XD200/2v2 includes a 12 dB / octave filter which can be configured as a low-pass or high-pass filter and offers continuously variable cutoff frequency selection from 50-500 Hz.

The XD200/2v2 also features the v2 Spec feature set, which consists of automatic turn-on capability (via signal sensing or DC-offset sensing), and a dual-range differential-balanced input section able to handle a wide range of input voltage levels. With the addition of an HD-RLC remote level control (sold separately), the amplifier's level can be directly controlled from the driver's seat.

This amplifier features a black powder-coat finish and a gasketed, brushed aluminum cover for the controls.

NexD™ Switching Technology

NexD™ amplifier technologies produce exceptional audio quality, unsurpassed total efficiency and high power from very compact amplifier designs.

Advanced Rollback Protection

JL Audio's exclusive Advanced Rollback Protection circuit monitors the amplifier's thermal condition and adjusts amplifier operation to eliminate annoying amplifier shut-down events

v2 Spec

An enhanced set of features added to XD and M-Series amplifiers that bear the "v2" designation make these models more versatile than ever.

Differential-Balanced Inputs

JL Audio’s Differential-Balanced Inputs are engineered to combat induced cable noise, which is a common problem in car and marine audio installations. This technology allows for the use of conventional RCA cables, while delivering many of the benefits of a true balanced connection and accepting a wide range of input signal levels.

Number of Channels

2

Class

D

Peak Power Rating (Watts)


RMS Power Rating (Watts x Channels) - 4 Ohms

75 x 2

RMS Power Rating (Watts x Channels) - 2 Ohms

100 x 2
RMS Power Rating (Watts x Channels) - 1 Ohm

N/A

RMS Power Rating - Bridged 200 x 1
Minimum Impedance Unbridged (Ohms)

2

Minimum Impedance Bridged (Ohms)
4
THD at Rated RMS Power

1%

Bulit-in Crossover - Low Pass

Yes

Built-in Crossover - High Pass
Yes
High Pass Crossover Frequency (Hz)

50-500hz

Low Pass Crossover Frequency (Hz)
50-500hz
Signal-to-Noise Ratio

84dB

Bass Boost
No
Bass Remote Included

No

Fuse Rating 30A
CEA-2006 Compliant Yes
Maximum Power Wire Gauge Size 4 Gauge
Warranty 1 Year
