JL Audio MX770-CCX-CG-TB, MX Series Narrow Flange 7.7" Marine Cockpit Coaxial Speakers, Infinite Baffle, Titanium/Black Classic Grille, 70W
Model: JL-MX770-CCX-CG-TB
UPC: 699440919265
JL Audio MX770-CCX-CG-TB, MX Series Narrow Flange 7.7" Marine Cockpit Coaxial Speakers, Infinite Baffle, Titanium/Black Classic Grille, 70W
Price Match Guarantee
60-DAY FREE & EASY RETURNS
Your purchase is backed by our AVLeaderz advantage satisfaction guarantee. Get Free & Easy Returns for 60 days from the day you receive your order.
Not Available for Shiping Outside the United States
Questions? We're here to help.
866-859-0896 ChatEmail UsGeneral Features:
- JL Audio 7.7" 2-Way MX-Series Marine Cockpit Coaxial System
- Power Handling:
- RMS: 140 watts per pair / 70 watts each
- Recommended Power Range: 20 - 150 watts RMS each
- Color: Black Frame w/ Titanium Classic Grille
- Injection-molded, mica-filled polypropylene cone with UV inhibitors
- Synthetic rubber surround
- 0.75" pure silk dome tweeter w/ Neodymium magnet
- Ferrofluid cooled and damped tweeter
- 1.00" (25 mm) voice coil
- Low-profile/ progressive-roll spider
- DMA-optimized, long excursion design
- UV-resistant polymer baskets and grilles
- Polyswitch solid-state tweeter protection
- Natural woofer roll-off with 2nd order high-pass circuits
![]()   |
- Top-mount Depth: 3.15 " (F)
- Cutout Dimensions: 6.25" (E)
- 4 ohms impedance
- Frequency Response: 45 - 25,000 Hz
- Sensitivity: 90.5 dB
- Authorized Internet Dealer
- 2 Year Manufacturer's Warranty

Priced Per Pair
Speaker Size |
7.7" |
Design |
2-Way |
Color | Black |
Water Resistance Rating | UV and Salt tested |
LED Illumination | Yes |
Tweeter Design |
3/4" Dome |
Impedance (Ohms) |
4 |
Tweeter Composition |
Silk |
Woofer Composition |
IMPP |
Woofer Surround |
Synthetic Rubber |
Sensitivity (dB) |
90.5dB |
Frequency Response (Hz) |
45 - 25k Hz |
RMS Power Rating (Watts) |
75 |
Peak Power Rating (Watts) |
225 |
Top-mount Depth (Inches) |
3 1/4 |
Bottom-mount Depth (inches) |
|
Cutout Diameter (inches) |
6 1/4 |
Grilles Included | Yes |
Warranty |
1-Year |
