Jensen JATWO Apex Series 2-Channel Class D Amplifier – 530 Watts
Enhance your vehicle’s audio system with the Jensen JATWO Apex Series 2-Channel Amplifier, designed to deliver powerful, efficient, and customizable sound performance in a compact package. Built with advanced Class D technology, the JATWO provides clean power for upgraded speakers while offering flexible installation options for both factory and aftermarket audio systems.
With 530 watts of maximum dynamic power, the JATWO delivers the extra performance needed to bring out stronger vocals, improved detail, and enhanced overall volume from your speakers. The 2-channel design allows you to power a pair of speakers independently or bridge the channels for increased output to a single speaker or subwoofer setup.
The amplifier provides 125 watts RMS x 2 channels at 4 ohms, 215 watts RMS x 2 channels at 2 ohms, and up to 445 watts RMS x 1 channel when bridged at 4 ohms. Adjustable crossover controls, variable bass boost, and gain adjustment allow you to fine-tune your system for balanced sound and optimized performance.
Featuring high-level speaker inputs and RCA inputs, the JATWO integrates easily with a wide range of factory and aftermarket receivers. Its compact Class D design helps maximize efficiency while minimizing installation space, making it an excellent choice for vehicles where performance and flexibility matter.
Key Features:
- Apex Series 2-channel Class D MOSFET amplifier
- 530 watts maximum dynamic power
- 125W RMS x 2 channels @ 4 ohms
- 215W RMS x 2 channels @ 2 ohms
- 445W RMS x 1 channel bridged @ 4 ohms
- 2/4-ohm stable stereo operation
- Adjustable high-pass, low-pass, and full-range crossover modes
- Variable bass boost at 45Hz (0–6 dB)
- Gain adjustment: 300mV–6V
- High-level speaker inputs for factory system integration
- RCA pass-through outputs
- Compact design for flexible installation
- CTA-2006 compliant
Specifications:
- Amplifier Class: Class D Digital
- Channels: 2
- Maximum Dynamic Power: 530 Watts
- RMS Power Output:
- 125 Watts x 2 @ 4 Ohms
- 215 Watts x 2 @ 2 Ohms
- 445 Watts x 1 Bridged @ 4 Ohms
- Frequency Response: 20Hz–20kHz
- Signal-to-Noise Ratio: 87 dBA
- Total Harmonic Distortion: <0.12%
- Crossover Range: 50Hz–250Hz
- Bass Boost: Variable 45Hz (0–6 dB)
- Input Sensitivity: 300mV–6V
- Fuse Rating: 30A
- Recommended Power/Ground Wire: 8 AWG
- Dimensions: Approx. 1.99" H x 6.54" D x 6.77" W
The Jensen JATWO Apex Series amplifier delivers the perfect combination of power, efficiency, and tuning flexibility for drivers looking to upgrade their car audio experience. Whether powering premium speakers or running a bridged configuration, the JATWO provides clean, reliable performance in a compact design.
