Hifonics ZD-3350.1D Zeus Delta Class-D Mono Block Subwoofer Amplifier – 3350 Watts
Unleash powerful, competition-level bass performance with the Hifonics ZD-3350.1D Zeus Delta Mono Block Super D-Class® Subwoofer Amplifier. Designed for serious car audio enthusiasts, this high-output amplifier delivers up to 3,350 watts of maximum power through an efficient mono block Class-D platform built for driving powerful subwoofer systems.
The ZD-3350.1D combines Hifonics’ advanced digital Class-D technology with a high-current PWM MOSFET power supply to deliver massive bass output while maintaining efficiency and thermal stability. Its compact Zeus Delta design provides exceptional power in a smaller installation footprint without sacrificing performance.
Key Features
-
3350 Watts Maximum Power Output for extreme low-frequency performance
-
Mono Block Class-D Design optimized specifically for subwoofer applications
-
3350W x 1 @ 1 Ohm for maximum bass output
-
1675W x 1 @ 2 Ohms for flexible system configurations
-
850W x 1 @ 4 Ohms for efficient subwoofer operation
-
PWM MOSFET Power Supply for stable high-current delivery
-
Super D-Class® efficiency for powerful output with reduced heat generation
-
Variable Electronic Crossover with 12dB/octave slope for precise tuning
-
Variable Low-Pass Filter (50Hz–250Hz) for bass control
-
Subsonic Filter (15Hz–40Hz) to eliminate unwanted ultra-low frequencies
-
Adjustable Bass Boost (0–12dB) for customized bass response
-
Built-in Bass Remote Control for convenient adjustment from the driver’s seat
-
Speaker-level inputs for compatibility with factory audio systems
-
Low-noise preamplifier circuit for cleaner signal processing
-
Nickel-plated RCA inputs for secure, reliable connections
-
LED protection diagnostics for overload and speaker protection
-
Aluminum heat sink design for improved cooling performance
Designed for Maximum Bass Impact
The Hifonics ZD-3350.1D Zeus Delta is engineered for enthusiasts who demand deep, hard-hitting bass without sacrificing control. The onboard crossover, subsonic filtering, and bass adjustment controls allow you to fine-tune your subwoofer system for powerful impact and accurate low-frequency response.
With its compact footprint and high-efficiency Class-D architecture, the ZD-3350.1D is an ideal solution for custom bass builds where maximum output and installation flexibility are priorities.
Specifications
-
Brand: Hifonics
-
Series: Zeus Delta
-
Model: ZD-3350.1D
-
Amplifier Class: Super D-Class® / Class-D
-
Channels: 1 Mono Block
-
Maximum Power Output: 3350 Watts
-
Power Output:
- 3350W x 1 @ 1 Ohm
- 1675W x 1 @ 2 Ohms
- 850W x 1 @ 4 Ohms
-
Frequency Response: 15Hz–250Hz
-
Total Harmonic Distortion (THD): <0.1%
-
Low-Pass Crossover: 50Hz–250Hz
-
Subsonic Filter: 15Hz–40Hz
-
Bass Boost: 0–12dB
-
Input Sensitivity: 0.2V–6V
-
Fuse Rating: External 175A
-
Recommended Power/Ground Wire: 2 AWG
-
Dimensions: 20.27" x 6.89" x 3.15"
-
Warranty: 1 Year
Why Choose the Hifonics ZD-3350.1D?
The Hifonics ZD-3350.1D Zeus Delta delivers the power and control needed for serious bass systems. With efficient Class-D technology, flexible impedance handling, advanced tuning features, and rugged construction, this amplifier is built to bring out the full potential of high-performance subwoofers.
Whether you are building a powerful daily system or a bass-focused custom installation, the ZD-3350.1D provides the output, reliability, and tuning flexibility required for an impressive audio experience.
