Hifonics HEW6D4-500P Elite 6" Powered Loaded Ported Subwoofer Enclosure – 500 Watts
Add powerful bass to your vehicle without taking up valuable space with the Hifonics HEW6D4-500P Elite 6" Powered Loaded Ported Subwoofer System. Designed as a complete all-in-one bass solution, this compact enclosure combines a 6-inch dual voice coil subwoofer with a built-in 500-watt Class-D amplifier inside a tuned ported enclosure for deep, controlled bass performance.
The HEW6D4-500P is engineered for vehicles where space is limited but enhanced low-frequency output is desired. With a factory-matched amplifier, integrated controls, and a loaded enclosure design, it provides a simple installation solution for upgrading factory or aftermarket audio systems.
Key Features
-
500 Watts Maximum Power Output for impactful bass performance
-
6" Elite Series Dual Voice Coil Subwoofer pre-installed in a ported enclosure
-
Built-in Class-D Mono Amplifier for efficient, space-saving installation
-
Dual 4 Ohm Voice Coil Design for optimized amplifier matching
-
500W x 1 @ 2 Ohms for maximum amplifier output
-
250W x 1 @ 4 Ohms for flexible system configurations
-
Tuned Ported MDF Enclosure for enhanced bass response and efficiency
-
Variable Low-Pass Crossover (50Hz–150Hz) for precise frequency control
-
Adjustable Bass Boost (0–12dB) for customized low-end impact
-
Subsonic Filter (15Hz–50Hz) to help control unwanted ultra-low frequencies
-
Wired Bass Remote Included for convenient bass level adjustment
-
Speaker-level input compatibility for integration with factory radios
-
High-efficiency Class-D circuitry for improved thermal performance
-
Protection circuitry with LED indicators for reliable operation
-
Compact enclosure design ideal for space-conscious installations
Compact Bass With Big Performance
The Hifonics HEW6D4-500P Elite powered subwoofer system combines the convenience of a built-in amplifier with the performance of a dedicated bass enclosure. The matched 6-inch subwoofer and amplifier work together to deliver strong bass output while minimizing installation complexity.
The ported enclosure design helps maximize efficiency and bass response, making this system a great option for cars, trucks, and SUVs where a traditional large subwoofer enclosure may not be practical.
Specifications
-
Brand: Hifonics
-
Series: Elite
-
Model: HEW6D4-500P
-
Type: Powered Loaded Ported Subwoofer Enclosure
-
Subwoofer Size: 6 Inches
-
Voice Coil Configuration: Dual Voice Coil
-
Voice Coil Impedance: Dual 4 Ohm
-
Amplifier Type: Class-D Mono Block
-
Maximum Power Output: 500 Watts
-
Power Output:
- 500W x 1 @ 2 Ohms
- 250W x 1 @ 4 Ohms
-
Low-Pass Crossover: 50Hz–150Hz
-
Subsonic Filter: 15Hz–50Hz
-
Bass Boost: 0–12dB
-
Input Sensitivity: 0.2V–9V
-
Signal-to-Noise Ratio: >100dB
-
Fuse Rating: 30A External
-
Recommended Power Wire: 8 AWG OFC
-
Enclosure Type: Ported MDF
-
Warranty: 1 Year
Why Choose the Hifonics HEW6D4-500P?
The Hifonics HEW6D4-500P Elite Powered Subwoofer System delivers a convenient way to add strong bass performance without the need for separate amplifier and enclosure purchases. Its compact 6-inch design, integrated Class-D amplifier, adjustable tuning controls, and loaded ported enclosure make it an excellent choice for drivers looking for a powerful yet space-efficient bass upgrade.
Enjoy cleaner, deeper bass with a streamlined installation solution built for modern vehicle audio systems.
